Automated Letter & Flats Mail Sorter

With options like the Recovery In-Line Labeler and Verifier and speed of up to 20,000 pieces per hour, It is the logical choice when looking for a complete sorter.

Send Email：[email protected]

Email INQUIRY

Product details

With options like the Recovery In-Line Labeler and Verifier and speed of up to 20,000 pieces per hour, It is the logical choice when looking for a complete sorter.

Features & Benefits

1.Throughput up to 20,000 pieces per hour.

2.The industry’s top performing Multi-Line Optical Character Reader (MLOCR) with text and handwritten capabilities.

3.Omni-Directional software-based barcode reader processes IMB, two-dimensional and linear barcodes.

4.It's sorter pocket design leverages patented anti jam technology for more reliable processing.

5.Requires only one operator and incorporates the popular Microsoft® Windows platform to minimize user training.

5.Distributed and transmission-free motor system reduces power consumption and downtime.

6.new Optesuite postal and analytics software package.

7.Can be configured for incoming and outgoing mail operations.

8.Processes letters and/or optionally flats up to 0.25” thick.

9.User-friendly diagnostic tools.

10.Recovery In-Line Labeler available.

11.Opener module available for Incoming mail.

12.Various pocket options.

Technical Specifications

Physical Mail Characteristics

LENGTH	Min 5″ (127 mm) / Max 11.5″ (292 mm)
HEIGHT	Min 3.5″ (88.9 mm) / Max 6.375″ (161.9 mm)
THICKNESS	Min 0.007″ (.178 mm) / Max 0.25″ (6.35 mm)

Power Requirements

VOLTAGE	208 VAC 3 phase Wye configuration
CURRENT	30 – 90 Amps per phase
FREQUENCY	60 Hz
– or –
VOLTAGE	415 VAC 3 phase Wye configuration
CURRENT	15 – 45 Amps per phase
FREQUENCY	50 Hz

Physical Mail Characteristics

LENGTH	Min 4” (101mm)/Max 24” (610mm) Greater Capacity Optional
WIDTH	Min 4” (101mm)/Max 20” (508mm) Greater Capacity Optional
HEIGHT	Min 0.197” (5mm)/Max 18” (457mm) Greater Capacity Optional
WEIGHT	Min 0.8 oz (23g)/ Max 60 lbs (27.2 kg)
